Optical Gaging Products (OGP®), a world-leading manufacturer of optical and precision multisensor metrology systems for industrial quality control, announces the addition of the new FlexPoint® 12-Series to its family of large format Multisensor Coordinate Measuring Machines. FlexPoint 12-Series systems expand the volume range of the FlexPoint family, offering solutions from 700 x 700 x 600 mm to 1200 x 3000 x 1000 mm.
Coordinate Measuring Systems
FlexPoint™ is the new generation of large format multisensor coordinate measuring systems from OGP®. FlexPoint offers a unique combination of sensors and CAD based programming, to solve a wide variety of dimensional measurement problems for large format parts.
The Multisensor Advantage
FlexPoint systems are true multisensor systems, supporting a wide range of tactile and non-contact sensors. These include SP25, SmartProbe®, a unique optical video probe, and the interferometric TeleStar® Probe. The SmartProbe is telecentric and has a large 12.5 mm x 9.5 mm FOV for high-speed 2D measurement. All sensors are powered by ZONE3® CAD based metrology software.
The VersaFlex™ multisensor head offers up to three simultaneously available sensors on an articulating probe head. With several sensors simultaneously available, there is no down time while exchanging individual sensors from a change rack. Likewise there is no need to recalibrate each time a sensor is used.
Powerful ZONE3 Software
ZONE3® CAD based metrology software provides complete flexibility for multisensor measurements – with or without a CAD model. An entirely graphical user interface, visual validation for every step, and graphical reporting make ZONE3 the easiest and most intuitive 3D metrology software available.
High Quality Construction
FlexPoint systems feature a stable transport design with carefully selected materials, rigid body members, air bearings on all axes, and active temperature compensation, to perform in shop floor environments. Unique and patented design features enable a larger measuring volume within a compact footprint.
Precise Compensation
Factory volumetric compensation using the Etalon® LaserTRACER system ensures the lowest possible compensation uncertainty. In the field, machine accuracy verification according to ISO 10360 is available.
